Criticality Analysis

Criticality analysis: What is it and how is it done?

Back to blog

Criticality and reliability-centered maintenance go hand-in-hand. Think about it: We’re told to prioritize PMs for critical assets, to build a TPM plan that accommodates critical pieces of equipment, and to perform root cause analysis on machinery that we consider to be high priority based on criticality. But how do we actually decide what makes a piece of equipment “critical”? In short, it all comes down to risk. Performing a criticality analysis allows you to understand the potential risks that could impact your business.

What is criticality analysis?

Criticality analysis is a systematic approach of assigning a criticality rating to assets based on their potential risks. Still sounds kind of abstract, right? How can risk be quantified? It helps to think about criticality analysis as part of a larger failure modes, effects [and criticality] analysis (FMEA / FMECA).

Learn how to fix a broken maintenance strategy with FMEA

Read more

As we’ve defined it recently, FMEA is an approach that identifies all possible ways that equipment can fail, and analyzes the effect those failures can have on the system as a whole. FMECA takes it a step further by conducting a risk assessment for each failure mode, and then prioritizing what corrective actions should be taken.

Download your free FMEA template here

Why is criticality analysis important?

As James Kovacevic of Eruditio describes, using a predetermined system to evaluate risk allows you to remove emotion from the equation. This ensures that reliability is truly approached from a risk-based point of view, rather than individual perception. Once equipment undergoes relative ranking based on its criticality, work can be properly prioritized and a condition monitoring strategy can be put in place. Performing an equipment criticality analysis also helps to clarify what can be done to reduce the risk associated with each asset.

Who’s responsible for criticality analysis?

So who actually carries out a criticality analysis? Industry experts say that it should be a cross-functional effort. We couldn’t agree more. It’s a much more effective process if input from operations, maintenance, engineering, materials management, and employee health and safety functions is considered. After all, risk can be defined differently for different teams. And since assigning risk will always be somewhat subjective, having a diverse background of knowledge to draw on will help to curb that.

How do you assess the criticality of an asset?

Asset criticality is the number value a business assigns to its assets based on their own set criteria. An asset criticality assessment can be done by creating a ranked list of work orders and orders in progress. This is known as an asset criticality ranking (ACR).

Learn more about how to create an ACR when developing an asset management model.

How to perform a criticality analysis

According to Kovacevic, there are two ways to carry out a criticality analysis. Both approaches produce a risk priority number (RPN) that allows you to rank the criticality level of each asset.

The first approach uses a criticality matrix, which is a 6×6 grid where severity of a given consequence (on the X axis) is plotted against the probability of that consequence occurring (Y axis). Naturally, if there is a high probability that a piece of equipment will fail in a way that causes great personal injury or severe operational issues, that piece of equipment is highly critical and should be prioritized accordingly. The number at the cross section of severity and priority for any piece of equipment is that piece of equipment RPN.

Conduct your own asset criticality analysis using this free resource

Download template

Criticality Analysis Grid

The second recommended approach is to separate the consequence categories by type (for example, health and safety, environmental, and operational). That way, you can rate how severe an equipment failure would be for each consequence category. For example, a piece of machinery that could cause severe personal injury upon asset failure would be a 5 or 6 in the health and safety category, but of almost no consequence to the environmental category (perhaps a 1 or 2), and moderately impactful to operations (somewhere in the middle). Once you’ve determined the severity of each consequence category for a given piece of equipment, you can multiply each of the categories together for that piece of equipment to get its RPN.

Criticality analysis by consequence category
Equipment Health & Safety Environmental Operational RPN
Forktruck 5 2 1 10
Conveyor system 2 1 4 8
Mixing tank 2 5 4 40


Once each piece of equipment has an RPN attached to it, you can rank them to assess which assets are critical. Kovacevic recommends grouping equipment into categories based on their RPN. Here are the categories he suggests:

Grouping assets by risk category
Risk Category RPN
Extreme Risk 107-125
High Risk 88-106
Medium Risk 37-87
Low Risk 19-36
No Risk 0-18


Once each piece of equipment is ranked, maintenance managers can make decisions that are informed by risk, rather than gut feel. From here, all reliability-related activities and processes will run much more smoothly.
